APL Exercises 2 ⎕io←0 throughout.
2.0 Factorial Write a function to compute the factorial function on integer ⍵ , ⍵≥0 . fac¨ 5 6 7 8 120 720 5040 40320 n←1+?20 (fac n) = n×fac n-1 1 fac 0 1 2.1 Fibonacci Numbers Write a function to compute the ⍵-th Fibonacci number, ⍵≥0 . fib¨ 5 6 7 8 5 8 13 21 n←2+?20 (fib n) = (fib n-2) + (fib n-1) 1 fib 0 0 fib 1 1 If the function written above is multiply recursive,
write a version which is singly recursive (only one occurrence of ∇).
Use cmpx to compare the performance of the two functions
on the argument 35 .
2.2 Peano Addition Let ⍺ and ⍵ be natural numbers
(non-negative integers).
Write a function padd to compute ⍺+⍵ without using +
itself (or - or × or ÷
).
The only functions allowed are comparison to 0
and the functions pre←{⍵-1} and suc←{⍵+1} .
2.3 Peano Multiplication Let ⍺ and ⍵ be natural numbers
(non-negative integers).
Write a function ptimes to compute ⍺×⍵ without using ×
itself (or + or - or ÷
).
The only functions allowed are comparison to 0
and the functions pre←{⍵-1} and suc←{⍵+1} and padd .
2.4 Binomial Coefficients Write a function to produce the binomal coefficients of order ⍵ , ⍵≥0 . bc 0 1 bc 1 1 1 bc 2 1 2 1 bc 3 1 3 3 1 bc 4 1 4 6 4 1 2.5 Cantor Set Write a function to compute the Cantor set of order ⍵ , ⍵≥0 . Cantor 0 1 Cantor 1 1 0 1 Cantor 2 1 0 1 0 0 0 1 0 1 Cantor 3 1 0 1 0 0 0 1 0 1 0 0 0 0 0 0 0 0 0 1 0 1 0 0 0 1 0 1 The classical version of the Cantor set starts with the interval [0,1]
and at each stage removes the middle third from each remaining subinterval: {(+⌿÷≢)Cantor ⍵}¨ 3 5⍴⍳15 1 0.666667 0.444444 0.296296 0.197531 0.131687 0.0877915 0.0585277 0.0390184 0.0260123 0.0173415 0.011561 0.00770735 0.00513823 0.00342549 (2÷3)*3 5⍴⍳15 1 0.666667 0.444444 0.296296 0.197531 0.131687 0.0877915 0.0585277 0.0390184 0.0260123 0.0173415 0.011561 0.00770735 0.00513823 0.00342549 2.6 Sierpinski Carpet Write a function to compute the Sierpinski Carpet of order ⍵ , ⍵≥0 . SC 0 1 SC 1 1 1 1 1 0 1 1 1 1 SC 2 1 1 1 1 1 1 1 1 1 1 0 1 1 0 1 1 0 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 1 1 1 1 0 1 0 0 0 1 0 1 1 1 1 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 0 1 1 0 1 1 0 1 1 1 1 1 1 1 1 1 1 ' ⌹'[SC 3] ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹ ⌹ ⌹ ⌹ ⌹⌹ ⌹ ⌹ ⌹⌹ ⌹ ⌹ ⌹ ⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹ ⌹⌹ ⌹⌹ ⌹ ⌹ ⌹⌹ ⌹⌹ ⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹ ⌹ ⌹ ⌹ ⌹ ⌹ ⌹ ⌹ ⌹ ⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹ ⌹⌹ ⌹⌹ ⌹ ⌹ ⌹⌹ ⌹⌹ ⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹ ⌹ ⌹ ⌹ ⌹⌹ ⌹ ⌹ ⌹⌹ ⌹ ⌹ ⌹ ⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹⌹⌹⌹ ⌹⌹⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ ⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹⌹ ⌹ ⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹⌹ 3-d analogs of the Cantor set and the Sierpinski carpet are the Sierpinski sponge or the Menger sponge.
2.7 Extended H Write a function for the extend H algorithm for ⍵ , ⍵≥0 , which embeds the complete binary tree of depth ⍵ on the plane. In xH ⍵ there are 2*⍵ leaves, instances of the letter o with exactly one neighbor (or no neighbors for 0=⍵). The root is at the center of the matrix. xH¨ ⍳5 ┌─┬─────┬─────┬─────────────┬─────────────┐ │o│o-o-o│o o│o-o-o o-o-o│o o o o│ │ │ │| |│ | | │| | | |│ │ │ │o-o-o│ o---o---o │o-o-o o-o-o│ │ │ │| |│ | | │| | | | | |│ │ │ │o o│o-o-o o-o-o│o | o o | o│ │ │ │ │ │ | | │ │ │ │ │ │ o---o---o │ │ │ │ │ │ | | │ │ │ │ │ │o | o o | o│ │ │ │ │ │| | | | | |│ │ │ │ │ │o-o-o o-o-o│ │ │ │ │ │| | | |│ │ │ │ │ │o o o o│ └─┴─────┴─────┴─────────────┴─────────────┘ Write a function that has the same result as xH but checks the result using the assert utility. For example: assert←{⍺←'assertion failure' ⋄ 0∊⍵:⍺ ⎕SIGNAL 8 ⋄ shy←0} xH1←{ h←xH ⍵ assert 2=⍴⍴h: assert h∊'○ -|': assert (¯1+2*1+⍵)=+/'o'=,h: h } 2.8 Tower of Hanoi
The Tower of Hanoi problem is to move a set of n different-sized disks from one peg to another, moving one disk at a time, using an intermediate peg if necessary. At all times no larger disk may sit on top of a smaller disk. Write a function Hanoi ⍵ to solve the problem of moving ⍵ disks from peg 0 to peg 2. Since it’s always the disk which is at the top of a peg which is moved, the solution can be stated as a 2-column matrix with column 0 indicating the source peg and column 1 the destination peg. Hanoi¨ ⍳5 ┌───┬───┬───┬───┬───┐ │ │0 2│0 1│0 2│0 1│ │ │ │0 2│0 1│0 2│ │ │ │1 2│2 1│1 2│ │ │ │ │0 2│0 1│ │ │ │ │1 0│2 0│ │ │ │ │1 2│2 1│ │ │ │ │0 2│0 1│ │ │ │ │ │0 2│ │ │ │ │ │1 2│ │ │ │ │ │1 0│ │ │ │ │ │2 0│ │ │ │ │ │1 2│ │ │ │ │ │0 1│ │ │ │ │ │0 2│ │ │ │ │ │1 2│ └───┴───┴───┴───┴───┘ Prove that Hanoi ⍵ has ¯1+2*⍵ rows. |
